| Place of Origin: | China |
|---|---|
| Brand Name: | BODA |
| Certification: | ISO9001:2015 |
| Model Number: | Sintered Tungsten Carbide Welding Bar |
| Minimum Order Quantity: | Negotiable |
| Price: | $60-65/kgs |
| Packaging Details: | 5kg/10kg per paper box |
| Delivery Time: | 7-15days |
| Payment Terms: | Negotiable |
| Supply Ability: | 10 tons/month |
| Manufacture: | Sintered | Chemistry: | Cast WC,Spherical Pallets,Ni Alloy |
|---|---|---|---|
| Purpose: | Wear Resistance,Anti-Corrosion | Specification: | Φ4.5±0.1mm ,Φ5±0.1mm |
| Highlight: | Tungsten Carbide Welding Bar,Sintered Tungsten Carbide Welding Bar,Anti Corrosion Sintered Welding Bar |
||
| Chemical composition ( Wt,%) | |||||||
| Specification(Diameter/length) | Hard-Phase | Bonding phase | |||||
| Φ 4.5±0.1mm | 410±10mm | Spherical Cast WC | Cemented Carbide Pellet | Nickcle Base Alloy Powder | |||
| Φ 5±0.1mm | 570±20mm | ||||||
| Typical Information | |||||||
| Coating Hardness: HRC 55-65 Applying Process :Oxy-acetylene Welding Coating Property :Wear resistance,Anti-Corrosion |
|||||||
Wire and Rods series products:
| Product | Regular Particle Size | Main Performance |
Spray Process |
Applicaitons |
| tubular welding rods | #2 Dia7*400mm 20-30mesh | Excellent wear resistance and impact resistance | Welding |
Surfacing of workpiece surface in metallurgy, construction, grain and oil processing, mining machinery and other industries. |
| #3 Dia6*400mm 30-40mesh | ||||
| #4 Dia 5*400mm 40-60mesh | ||||
| #5 Dia4*400mm 60-80mesh | ||||
| Flexible welding rope | Dia4mm: F:0.2-0.4mm M:0.4-0.7mm C:0.7-1.2mm |
Wear resistance,Anti-Corrosion | Oxy-acetylene Welding |
Oil bit, stabilizer , geological bit, feed screw etc. |
| Dia6mm: F:0.2-0.4mm M:0.4-0.7mm C:0.7-1.2mm |
||||
| Dia8mm: F:0.2-0.4mm M:0.4-0.7mm C:0.7-1.2mm |
