| Place of Origin: | China |
|---|---|
| Brand Name: | BODA |
| Certification: | ISO9001:2015 |
| Model Number: | BD10301 |
| Minimum Order Quantity: | Negotiable |
| Price: | $50-55/kgs |
| Packaging Details: | 50kg/Steel Drum,25kg/Steel Drum,10kg/Bottle,10 or 20 bottles in a pallets |
| Delivery Time: | 7-15days |
| Payment Terms: | Negotiable |
| Supply Ability: | 10 tons/month |
| Classification: | Carbide, Tungsten-based | Chemistry: | 86WC 10Co 4Cr |
|---|---|---|---|
| Manufacture: | Agglomerated And Sintered | Morphology: | Spheroidal |
| Purpose: | Corrosive Wear Resistance | Process: | HVOF, HVAF,Atmospheric Plasma |
| Highlight: | WC-Co-4Cr Coating,WC-10Co-4Cr,WC-CO Thermal Spray Materials |
||
HVOF Thermal Spray Powder WC-10Co-4Cr (WC/CO/CR 86/10/4)
Chemicals Compositon:
| Grade | T.C | Co | Cr | Fe | Process |
| BD10301 | 5.0-5.5 | 9.1-10.5 | 3.0-4.5 | ≤0.1 | Agglomerated & Sintered |
Product Introduction:
This product is dark brown gray spherical powder.
The sphericity of the powder is better, which ensures good fluidity.
The holes on the sphere are more uniform, so that the powder can be heated uniformly in the flame.
Coating properties:
Microhardness: 1250-1350Hv
Porosity: less than 1%
Combined strength: above 70MPa
Applicable temperature: less than 540 degrees Celsius under oxidizing atmosphere
Application areas:
The addition of Cr in WC-Co not only maintains excellent abrasive wear resistance, but also improves the corrosion resistance of the coating. In recent years, HVOF is used to prepare WC-Co-Cr coatings on the gas turbine, water generator, aero engine, aircraft landing gear components and all kinds of ball valve parts in the oil industry to improve the anti-corrosion and anti-wear properties of these parts. In addition, the WC-Co-Cr coating for HVOF spraying has also been proved to have excellent abrasive wear resistance on the surface protection of water conservancy machinery parts.
Our products range of WC-Co series:
| Product | Particle Size | Equal to | Main Performance | Spray Process | Applicaitons |
| WC-10Co-4Cr | 45-15um | Woka 3651 3652 3653 3654 3655 3665 |
Corrosive wear resistance | HVOF,HVAF,Atmospheric Plasma | Landing gears |
| 45-11um | Paper manufactureing rolls,Corrugating rollers | ||||
| 38-10um | Ball,gate and dump valves | ||||
| 25-5um | Hydroturbine buckets | ||||
| WC-12Co | 53-20um | Woka 3101, Woka 3102, Woka 3103, Woka 3105, |
Wear resistance | HVOF,HVAF,Atmospheric Plasma | Steel rolls |
| 45-15um | Corrugating rollers | ||||
| 38-10um | Sucker rod couplings | ||||
| 25-5um | Conveyor screws | ||||
| WC-17Co | 53-20um | Woka 3201 3202 3203 3205 3208 |
Ductile Wear resistance | HVOF,HVAF,Atmospheric Plasma | Landing gears |
| 45-15um | Pump seals | ||||
| 38-10um | Exhaust fans | ||||
| 25-5um | Crushing rollers |
Our factory and Lab:
