Detail Information

Color:	Dark Gray	Shape:	Spherical
Application:	Mainly Used In Mechanical Parts ,oil And Gas Equipment,metallurgical Roller And Pump Sel Units Etc	Operating Temperature:	500 ℃
Name:	Thermal Spray Powders	Manufacture:	Agglomerated And Sinterd Or Sintered And Crushed
Highlight:	Agglomerated And Sintered Thermal Spray Powders , 20um Thermal Spray Powders , 45um wc co powder

Product Description

WC-12Co 88/12 Agglomerated And Sinterd Or Sintered And Crushed HVOF Spray Powder

Chemical Composition:

Grade	Ct (Total Carbon)%	Ni %	Fe %	O %
BD-10202	5.1-6.0	11.0-13.0	＜0.2	＜0.2

Specification & Physical Properties:

Specs.	Type	Size um	Apparent density g/cm3	Flow rate s/50g	Application
BD-10202-1	WC-Co 88/12 Agglomerated and sintered	53-20	＞4.0 g/cm3	＜25s/50g	HVOF JP5000 JP8000 DJ2600 DJ2700 Jet Kote Woka Jet/K2 HVAF APS
BD-10202-2	WC-Co 88/12 Agglomerated and sintered	45-20	＞4.0 g/cm3	＜25s/50g
BD-10202-3	WC-Co 88/12 Agglomerated and sintered	45-15	＞4.0 g/cm3	＜25s/50g
BD-10202-4	WC-Co 88/12 Agglomerated and sintered	45-11	＞4.0 g/cm3	＜25s/50g
BD-10202-5	WC-Co 88/12 Agglomerated and sintered	38-10	＞4.0 g/cm3	＜25s/50g
BD-10202-6	WC-Co 88/12 Agglomerated and sintered	30-10	＞4.0 g/cm3	＜25s/50g
BD-10202-7	WC-Co 88/12 Agglomerated and sintered	30-5	＞4.0 g/cm3	＜25s/50g

Introduction:

These products are spheroidal powders for thermal spraying containing 88 % tungsten carbide as a hard material and a cobalt matrix that functions as a binder material for the carbide particles. All products are agglomerated and sintered powders
Coatings of these materials are harder compared to coatings of 83WC-17Co as a result of higher tungsten carbide levels.
Coatings are resistant to sliding wear, hammer (impact) wear,abrasion and fretting at temperatures up to 500 °C (930 °F)
in non-corrosive media.
Coatings that contain tungsten carbide protect substrates from the effects of fretting, abrasive grains, particle erosion,cavitation and dynamic contact with hard surfaces. In particular, these materials can be used for abrasion-resistant coat-
ings in dry, non-corrosive environments at temperatures up to 500 °C (930 °F).
HVOF and APS (using a TriplexPro™ series gun) coatings of these materials are dense and show good bond strength.

Typical Uses and Applications :

Tungsten carbide – 12 cobalt materials from BODA are among the best-known thermal spray powders for use in
wear applications at service temperatures below 500 °C (930 °F) in non-corrosive media. Typical applications include:
* Steel rolls
*Sink rolls in zinc pots
*Corrugating rollers
*Agricultural rasp bars
*Exhaust fans
*Conveyor screws
*Sucker rod couplings
*Thread bars
*Pump housings
*Impeller shafts

Tag:

Place of Origin:	China
Brand Name:	BODA
Certification:	ISO9001:2015,ISO14001
Model Number:	BD-10202

Minimum Order Quantity:	50kg
Price:	US$52.0/kg-$54.00/kg EX-WORK
Packaging Details:	10kg per bottle or 50kg per drum
Delivery Time:	5-8 working days
Payment Terms:	T/T
Supply Ability:	10-15 tons per month
