| Place of Origin: | China |
|---|---|
| Brand Name: | Shoulder Powder for PDC Drill Bit |
| Certification: | ISO9001:2015 |
| Model Number: | Cystalline Tungsten Powder |
| Minimum Order Quantity: | 50kgs |
| Price: | $48-55.0/kgs |
| Packaging Details: | 50kgs/Drum |
| Delivery Time: | 7-10days |
| Payment Terms: | Negotiation |
| Supply Ability: | 15tons/Month |
| Apparent Density: | 6.5-9.0g/cm3 | Chemical Formula: | W |
|---|---|---|---|
| Product Name: | Shoulder Powder For PDC Drill Bit | Hall Flow Rate: | ≤12.0 S/50g |
| Purity: | 99.8% | Particle Size: | 60-325mesh |
| Appearance: | Gray Powder | ||
| Highlight: | Diamond Bits Metal Carbide Powder,99.8% Metal Carbide Powder,PDC Drill Bit Tungsten Powder |
||
Crystalline Tungsten Powder/Tungsten Metal Powder
| Chemical Composition ( Wt,%) | |||||||
| W | Fe | O | Mo | Ni | Cr | Co | Cu |
| >99.7 | <0.1 | <0.06 | <0.01 | <0.04 | <0.015 | <0.01 | <0.01 |
| Typical information | |||||||
| Products | Particle Size | Apparent Density (g/cm3) | Hall Flow Rate (S/50g) | ||||
| Tungsten Metal Powder | 60-325mesh | -250+45um | 6.5-9.0 | ≤12.0 | |||
| 60-270mesh | -250+53um | ||||||
| 100-325mesh | -150+45um | ||||||
| 140-325mesh | -106+45um | ||||||
Crystalline tungsten powder is a type of tungsten powder with extremely high purity.
The powder is composed of fully carbonized and dense tungsten carbide, which has a homogeneous micro-structure and is light gray in color.
Its excellent thermal stability is the result of precisely chosen raw materials and special alloying during the manufacturing process.
Crystalline tungsten powder has a broad range of applications.
It is used as the raw materials of oil perforation pills in petroleum drilling diamond bits, as well as for high temperature combustion-chamber spraying coating, parts coating with high temperature resistance, and as the tungsten crucible in intermediate frequency furnaces.
High Density: Crystalline tungsten has one of the highest densities among metals, making it an ideal choice for applications that require weight or mass concentration.
Its high density enables it to be used as ballast weights in aircraft, projectiles, and other systems where precise balance is crucial.
Refractory Properties: Tungsten has excellent refractory properties, meaning it can withstand high temperatures without melting or deforming.
This characteristic makes it suitable for use in high-temperature applications such as furnace components, rocket nozzles, and crucibles for melting and casting metals.
Excellent Machinability: Despite its exceptional hardness, crystalline tungsten can be machined and fabricated into various shapes and forms.
Its machinability allows for the production of intricate components and precise parts used in industries such as aerospace, automotive, and mining.
Low Thermal Expansion: Crystalline tungsten exhibits low thermal expansion, meaning it expands and contracts minimally with changes in temperature.
This property ensures dimensional stability, making it valuable for applications where precision and consistency are essential, such as in precision instruments and scientific equipment.
Environmental Compatibility: Tungsten is considered an environmentally friendly material due to its non-toxic nature and high recyclability.
It is free from harmful substances and can be easily recycled and reused, contributing to sustainable manufacturing practices.
Versatility: Crystalline tungsten products find applications in a wide range of industries including aerospace, defense, electronics, energy, mining, and healthcare.
They are used in diverse applications such as light bulb filaments, electrical contacts, X-ray shielding, drilling tools, and vibration-damping components.
Longevity and Reliability: Thanks to its exceptional strength, durability, and resistance to corrosion and wear, crystalline tungsten products have a long service life and offer excellent reliability in demanding environments.
This makes them a preferred choice for critical and high-performance applications where reliability is paramount.
Overall, crystalline tungsten products possess a unique combination of properties that make them highly desirable and versatile materials across industries.
Their high density, refractory properties, machinability, low thermal expansion, environmental compatibility, and reliability contribute to their widespread use and importance in various applications.
| Attribute | Value |
|---|---|
| Purity | 99.8% |
| Product Name | Shoulder Powder For PDC Drill Bit |
| Particle Size | 60-325mesh |
| Appearance | Gray Powder |
| Apparent Density | 6.5-9.0g/cm3 |
| Hall Flow Rate | ≤12.0 S/50g |
| Chemical Formula | W |
| Keywords | Crystalline Tungsen Powder, High purity Tungsten Powder, Tungsten Powder for PDC |
Crystalline tungsten products are ubiquitous across many sectors for their superior properties.
In the electrical and electronics industry, they are widely used in the production of filaments for incandescent lamps, cathodes for electron emitters, and electrical contacts that require excellent conductivity and stability.
As for their exceptional hardness and wear resistance, crystalline tungsten is an ideal choice for cutting tools such as drills and milling cutters, as well as for making wear-resistant parts in mining and metalworking.
Crystalline tungsten is also heavily applied in aerospace and defense for its high density, and is found in ballast weights, counterweights, and gyroscopes.
Furthermore, due to its shielding ability, crystalline tungsten has become a staple in medical and industrial settings that require radiation protection from X-rays and gamma rays.
Moreover, crystalline tungsten is exceptionally resistant to high temperatures, making it the go-to material for furnace components and rocket nozzles.
In conclusion, the superior properties of crystalline tungsten enable its applications in many essential industries, allowing for improved performance and technological progress.
We provide customised services for Tungsten Metal Powder, featuring Metal Carbide Powder, High purity Tungsten Powder, Cystalline Tungsten Powder and ISO9001:2015 certification. The details are as follows:
Tungsten metal powder is typically packaged in sealed containers and shipped either in barrels or drums.
The container should be lined with an inert material to protect the powder from moisture and contamination.
The containers should be labeled with the product name, weight, and other relevant information.
The powder should be shipped in a manner that prevents it from coming into contact with any other material, and the shipping method should be able to protect the containers from any physical damage.
