Wear Protection Metal Carbide Powder Chromium Carbide Powder 325-5.5um

Basic Information
Place of Origin: China
Brand Name: BODA
Certification: ISO9001:2015,ISO14001
Model Number: BD-30101 BD-30102 BD-30103 BD-30104 BD-30105
Minimum Order Quantity: 50kg
Price: US$18.0/kg-$26.0/kg EX-WORK
Packaging Details: 50kg per drum or 100kg per drum
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 20-30 tons per month
Detail Information
Color: Dark Gray Shape: Irregular
Chemicals: Ct 12.5% Max Cf 0.5% Max Cr 85.5%min Size: -11um ,140-325mesh 325-5.5um
Item: Chromium Carbide Powder
Highlight:

Wear Protection Metal Carbide Powder

,

5.5um Metal Carbide Powder

,

5.5um Chromium Carbide Powder


Product Description

Chromium Carbide Powder Used As An Additive In Cutting Tools Made Of Cemented Carbides Also As Surface Treatment

Chemical Composition:



Grade Ct Cf Cr Fe Si O Al P S
BD-30101 ≥12.75 ≤ 0.3 ≥85.5 ≤0.5 ≤0.15 ≤0.5 ≤0.15 ≤0.02 ≤0.035
BD-30102 ≥12.75 ≤ 0.3 ≥85.5 ≤0.5 ≤0.15 ≤0.5 ≤0.15 ≤0.02 ≤0.035
BD-30103 ≥12.75 ≤ 0.3 ≥85.5 ≤0.5 ≤0.15 ≤0.5 ≤0.15 ≤0.02 ≤0.035
BD-30104 ≥12.75 ≤ 0.3 ≥85.5 ≤0.5 ≤0.15 ≤0.5 ≤0.15 ≤0.02 ≤0.035
BD-30105 ≥12.75 ≤ 0.3 ≥85.5 ≤0.5 ≤0.15 ≤0.5 ≤0.15 ≤0.02 ≤0.035






Specification :



Grade  Average Particle Size
BD-30101  ≤11um
BD-30102 2-3um
BD-30103 ≤2um
BD-30104 140-325mesh
BD-30105 325-5um



Chromium carbide is useful in the surface treatment of metal components. Chromium carbide is used to coat the surface of another metal in a technique known as thermal spraying. Cr3C2 powder is mixed with solid nickel-chromium. This mixture is then heated to very high temperatures and sprayed onto the object being coated where it forms a protective layer. This layer is essentially its own metal matrix composite, consisting of hard ceramic Cr3C2 particles embedded in a nickel-chromium matrix. The matrix itself contributes to the corrosion resistance of the coating because both nickel and chromium are corrosion resistant in their metallic form. After over spraying the coating, the coated part must run through a diffusion heat treatment to reach the best results in matter of coupling strength to the base metal and also in matter of hardness.
Another technique utilizes chromium carbide in the form of overlay plates. These are prefabricated chromium carbide-coated steel plates, which are meant to be welded onto existing structures or machinery in order to improve performance.
Chromium carbide is used as an additive in cutting tools made of cemented carbides, in order to improve hardness by preventing the growth of large grains.[8] The primary constituent in most extremely hard cutting tools is tungsten carbide. The tungsten carbide is combined with other carbides such as titanium carbide, niobium carbide, and chromium carbide and sintered together with a cobalt matrix. Cr3C2 prevents large grains from forming in the composite, which results in a fine-grained structure of superior hardness.
Undesired formation of chromium carbides in stainless steel and other alloys can lead to intergranular corrosion.
